Labstar Headsets are designed to be durable and comfortable for extended wear. Our German "DE" series headsets are and are virtually indestructible. Some of our customers have owned theirs for over 15 years. Our "C" series headsets provide a more economical approach and are ideal for walk-in labs where students are responsible for their own headsets.

DE-2500

TECHNICAL DATA

Headphone Section
Freq Response: 16 - 21,000 Hz
Driver: dynamic
Acoustic Principle: closed
Nominal Impedance: 100 ohms
Cont. Power Rating: 100 mW
Ave Pressure on the Ear: ~ 6 N
Weight w/o Cable: 270/200 g

Microphone Section
Microphone Type: electret
Freq Response: 40 - 18.000 Hz
Pattern: cardioid - cancelling
Nominal Impedance: 1000 ohms
Sensitivity: 16.25 mV/Pa
Phantom Power: 1.5 - 9 V
Front-to-Back Ratio: 15 dB
Connector: 3.5mm plug x 2

C-500

TECHNICAL DATA

Headphone Section
Freq Response: 20 ~ 20,000 Hz
Driver: dynamic
Acoustic Principle: closed
Nominal Impedance: 40 ohms
Sensitivity: 110 dB @ 1Khz
Maximum Power Rating: 500 mW
Weight w/o Cable: 200 g

Microphone Section
Microphone Type: electret
Freq Response: 40 - 16.000 Hz
Pattern: cardioid - cancelling
Nominal Impedance: 1000 ohms
Sensitivity: -60dB @ 30mm
Phantom Power: 4.5 V
Connector: 3.5mm plug x 2

C-202V

TECHNICAL DATA

Headphone Section
Freq Response: 20 ~ 20,000 Hz
Driver: dynamic
Acoustic Principle: semi-closed
Nominal Impedance: 32 ohms
Sensitivity: 112 dB @ 1Khz
Maximum Power Rating: 500 mW
Weight w/o Cable: 190 g

Microphone Section
Microphone Type: electret
Freq Response: 40 - 16.000 Hz
Pattern: cardioid - cancelling
Nominal Impedance: 1000 ohms
Sensitivity: -60dB @ 30mm
Phantom Power: 4.5 V
Connector: 3.5mm plug x 2

Indestructible!

Labstar Headsets Indestructible!

DE Series

The DE-2500 headset is specifically designed for demanding applications such as language laboratories and computer classrooms, where quality, reliability, and comfort are of utmost importance.

The virtually indestructible housings are made of a special flexible PE material.

Soft, gentle ear pads provide comfort even for the longest lasting audio sessions.

The flexible yet unbreakable microphone boom is molded from a single die with the left headphone housing and can be bent into any required position.

_________________________

C Series

The C Series headsets have been thoroughly tested in the harshest learning environments in the world and have come through with shining colors. They sound great too!

Optional integrated volume controls allow individuals to listen in comfort at any level.

These lightweight units are comfortable to wear for hours at a time.
